AG705G |
Aluminum-Glass Cloth backing (7u Foil / FR Glue / 12x12 Mesh Glass) |
AG705H |
Aluminum-Glass Cloth backing (7u Foil / Polyethylene / 12x12 Mesh) |
AG725G |
Aluminum-Glass Cloth backing (7u Foil / FR Glue / 12x12 Mesh Glass) |
AG725H |
Aluminum-Glass Cloth backing (7u Foil / Polyethylene / 12x12 Mesh) |
AG725R |
Aluminum-Glass Cloth backing (7u Foil / FR Glue / 90gsm Glass Cloth) |
AG1825R |
Aluminum-Glass Cloth backing (18u Foil / FR Glue / 8 x 8 Mesh Glass) |
|
Backing |
Adhesive |
Thickness Micron |
Adhesion N/25mm |
Tensile N/25mm |
Elongation % |
Service Temp°C |
AG705G |
Alum.-Glass |
Rubber-Resin |
160 |
18 |
255 |
5 |
-20 ~ +80 |
AG705H |
Alum.-Glass |
Rubber-Resin |
175 |
18 |
265 |
5 |
-20 ~ +80 |
AG725G |
Alum.-Glass |
solvent acrylic |
170 |
18 |
255 |
5 |
-30 ~ +120 |
AG725H |
Alum.-Glass |
solvent acrylic |
185 |
18 |
265 |
5 |
-30 ~ +120 |
AG725R |
Alum.-Glass |
solvent acrylic |
170 |
18 |
255 |
5 |
-30 ~ +120 |
AG1825R |
Alum.-Glass |
solvent acrylic |
180 |
20 |
255 |
5 |
-30 ~ +120 |
